Rims: WTB HTZ i30 27.5''

• ETRTO 584-30

• Inner width: 30mm

• 6061 series aluminum

• Asymetric and angled spoke hole drilling distributes spoke tension more evenly

• Reinforced I-Beam profile

• Strong sleeved joint

• Drilled for Presta valve

• TCS 2.0 Tubeless System compatible

• Solid Strip included

• Tubeless valve included

• 32 holes

  Front hub: Shimano XT HB-M8110-B Boost

• 15x110mm (Axle not included)

• Center Lock (6-Bolt adapter included)

• Polished angular contact bearings

• Contact sealed hub

  Rear hubs options: Shimano XT FH-M8010-B (Boost, HG) / FH-M8110-B (Boost, MS) / FH-M8130-B (SuperBoost, MS)

• Center Lock (6-Bolt adapter included)

• Quick Engagement Freehub, 36 Points of Contact, 10 deg. engagement

• HG compatible Shimano 11spd and Sram NX / SX splined 12spd (10spd and below needs spacer)

• MS compatible 12 Spd Shimano Micro Spline

  Assembled in North America by experienced wheelbuilders with Sapim Race spokes (Black), Polyax Nipples (Black)

Attributes

Rim Internal Width	30mm
Spoke Type	Sapim Race
Depth	19mm
Rim Drilling	32
Valve	Presta
Rim External Width	34mm
Wheel Diameter/ISO	27.5'' / 584
Rim inner width range	28-34.9mm
Skewers Included	No
Wheel-Brake Comp.	Disc Center Lock / IS 6-Bolt
Rim Color	Black
Rim Material	Aluminum
Rim Model	WTB HTZ i30
Wheel Tire Type	Tubeless Compatible
Rim Construction	Double wall, Sleeved
